Hose Arrestor / whip Lash

Price 550 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Hose Arrestor / whip Lash Specification

Control Type
Passive safety control.

Features
Anti-whip design, robust construction, easy installation, corrosion resistant, reusable.

Working Temperature
-30C to +80C (approximate, may vary by material).

Fire Extinguisher Type
Not applicable.

Connectivity Type
Mechanical clamp-on attachment to hose.

Voltage
Not applicable.

Coating Type
Zinc-plated or stainless steel for corrosion resistance.

Fire Class
Not applicable.

Energy Efficiency Rating
Not applicable.

Technology
Heavy-duty wire rope sling with steel safety clips.

Operating Pressure
Up to 700 bar (dependent on specific hose and arrestor configuration).

Installation Type
Clamp-on installation, no special tools required; can be retrofitted to existing hoses.

Shape
Cable loop with securing clips.

Mounting Type
Inline attachment at hose ends.

Coverage Area
Covers area immediately around high-pressure hoses.

Application
Safety device for hose restraint, used to prevent whiplash injury in case of hose failure.

Max Flow Rate
Not applicable (device is for mechanical restraint, not fluid transfer).

Diameter
Varies according to hose size; typically available for 1/2 inch to 3 inch hoses.

Capacity
Depends on model; selected based on hose diameter and operating pressure.

Pressure
Suitable for high pressure hoses; actual rating depends on hose specification.

Length
Typically ranges from 400 mm to 1200 mm according to hose length.

Weight
Varies by size, typically between 0.5kg-2kg.

Compatibility
Compatible with compressed air, hydraulic and water hoses.

Maintenance
Inspection recommended every 6 months; replace if any signs of wear or damage.

Material
Galvanized steel wire or stainless steel.

Color
Metallic/silver (galvanized or stainless steel finish).

About Hose Arrestor / whip Lash

Specifications:

These are the best high-pressure hose restraints available, because the stocking style woven steel grips the hose more securely over a larger area
Abrasion and wear and tear usually take place near fittings, which may result in a rupture.
The woven steel can also help prevent abrasion to the hose underneath
These Whip Socks are not restricted to just air hoses, but can be used on any application where high-pressure hoses are used, air, water, hydraulic, slurry, etc.
Make: U-Safe
Availability: Pune, Chennai, Ahmedabad, Bengaluru, Hyderabad, Visakhapatnam, Cochin, Vadodara, Kolkata, Delhi, etc

Reliable Hose Safety Solution

The Hose Arrestor provides peace of mind for operators working with high-pressure hoses, mitigating the risk of dangerous whiplash incidents. Its durable, metallic construction withstands harsh environments and significant pressure. Compatibility with various industrial hoses makes it a versatile safety option for factories, warehouses, and field operations.

Corrosion-Resistant and Reusable Design

Featuring zinc-plated galvanized steel or stainless steel construction, the Hose Arrestor offers robust corrosion resistance for longevity. The device can be reused across multiple installations if free of damage, and its passive clamp-on system enables quick attachment and removal without the need for special tools.

FAQs of Hose Arrestor / whip Lash:

Q: How is the Hose Arrestor installed onto a hose?

A: The Hose Arrestor is mounted inline at the hose ends using a clamp-on mechanism with steel safety clips. It requires no special tools and can be retrofitted to existing hoses quickly and efficiently.

Q: What materials are used in the Hose Arrestor construction?

A: Hose Arrestors are made from galvanized steel wire or stainless steel, which provides excellent mechanical strength and corrosion resistance for a long service life.

Q: When should the Hose Arrestor be inspected or replaced?

A: Routine inspections are recommended every six months. If signs of wear, damage, or corrosion appear during an inspection, replacement is necessary to maintain safety standards.

Q: Where can the Hose Arrestor be applied?

A: This device is suitable for environments utilizing compressed air, hydraulic, or water hoses where safety against whip lash is requiredsuch as manufacturing sites, refineries, and construction projects.

Q: What is the purpose and benefit of using a Hose Arrestor?

A: The Hose Arrestor prevents hoses from whipping uncontrollably if a failure occurs, significantly reducing the risk of injury to personnel and damage to equipment in the vicinity.

Q: What hose sizes and operating pressures can this device accommodate?

A: It is designed for hoses ranging from 1/2 inch to 3 inches in diameter and can support operating pressures up to 700 bar, provided the hose and arrestor configuration are compatible.
